Battery Energy Full-Scene Intelligent Charging

Scheme

AC / DC Smart Charging Solution

PDDC / DC Two-Way Charging Solution

Industrial-Grade PD Power Supply Charging Solution

DC / DC Charging Solution

Wireless Charging Solutions

Battery Platform

3 The Cells 12V/2A/3A/4.5A Platform

4 Cells 21V / 2A / 3A Platform

5 Cells 21V / 3A / 4A / 5A / 6A / 8A / 12A Platform

10 Cells 42V / 2A / 4A / 8A / 12A Platform

14 Cells 58V / 5A / 9A / 12A Platform

20 Cells 84V / 12A Platform

28 Cells 118V/8.5A/12A Platform

Main Feature 1 Main Feature 2

Battery Voltage

1V - 118V

Charging Current

0.1C - 4C

Charging Port

Single / Double / Multiple

Protocol

CAN-FD / CAN / RS485 / SPI / I2C

Battery Type

Ternary lithium battery / lithium iron phosphate battery / sodium ion battery / ni-mh Battery / lead-acid battery

Other

Dual software / hardware charging protection DC/DC PD bidirectional charging

Battery Voltage

1V - 118V

Charging Current

0.1C - 4C

Power Tools Power Station Solution

Main Feature

Output

14-56VDC 100V-240VAC 50/60Hz

Power Range

400W-3KW

High Energy Efficiency

The highest was 92% , which met the standard of ERP Lot 7 & Doe VI

Protection

OCP / UVP / OVP / OTP

Input

AC: 100V-240V 50/60Hz TYPE-C input: 100 Wmax Pv Input: 11-60VDC, 1000W max. Cigarette lighter input: 12V / 10 Amax

Other

In line with the global safety regulations & environmental protection; High energy efficiency, high density, miniaturization, digital, intelligent charging; DC-DC bidirectional charging supports standby power consumption below 20 uA DC-DC bidirectional charging supports HUB function (with no battery, input from any USB-C port, other three-way output)
